The DLE Gas Engine Kill Switch V2.0 (DLEG9205) is a premium optically isolated electronic ignition cut-off device designed for gasoline-powered RC aircraft engines. Engineered to provide maximum operational safety, the kill switch allows pilots to remotely disable the engine ignition directly from a transmitter-controlled receiver channel.
Utilizing advanced fiber-optic isolation technology, the V2.0 Kill Switch completely separates the ignition system from the radio system, significantly reducing the risk of electrical interference and ignition noise affecting receiver performance. The integrated MOSFET switching circuitry provides reliable operation with low voltage drop and supports a wide range of ignition battery configurations.
An external high-visibility LED status indicator clearly shows when the ignition system is armed, enhancing safety during engine start-up, handling, and flight operations. The compact and lightweight design makes it suitable for virtually all gasoline-powered RC aircraft, including models equipped with DLE, DA, DLA, EME, GP, and similar electronic ignition engines.
Key Features
- Remote engine shut-off from transmitter
- Fiber-optically isolated input/output design
- Eliminates ignition-to-radio interference
- High-current MOSFET switching circuit
- Bright external LED ignition status indicator
- Reverse polarity protection
- Compatible with most RC ignition systems
- Universal connectors for easy installation
- Compact and lightweight construction
- Essential safety device for gasoline-powered aircraft
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | DLE Gas Engine Kill Switch V2.0 |
| Part Number | DLEG9205 |
| Type | Optically Isolated Electronic Kill Switch |
| Controller | PIC12F675 Microcontroller |
| Isolation Method | Fiber Optic Coupling |
| Output Device | MOSFET (IRF7456) |
| Maximum Output | 20V / 16A |
| Minimum Operating Output | 3V / 3A |
| Voltage Drop | Less than 150mV |
| Battery Compatibility | LiPo, Li-Ion, LiFe (A123), NiMH, NiCd |
| Receiver Connection | Standard Receiver Channel |
| LED Indicator | Remote Mount LED Included |
| Dimensions | 17 × 38 × 7.5 mm |
| Weight | Approx. 8 g |
| Application | Gasoline RC Aircraft Engines |
Applications
- RC Aerobatic Aircraft
- Giant Scale Aircraft
- UAV Platforms
- Gasoline-Powered RC Models
- DLE Engine Installations
- DA, DLA, EME and similar ignition systems
Benefits
- Improves flight safety by providing immediate engine shutdown capability.
- Prevents ignition noise from affecting radio equipment.
- Reduces risk of runaway engines during emergencies.
- Enhances ground handling and maintenance safety.
- Supports receiver failsafe programming for automatic engine shutdown.
