Compatible Applications
1/8, 1/10-scale buggies, truggies, crawlers, and monster trucks. Also suitable for airplanes, boats (electric or nitro-powered).
Performance Specs
|
Voltage |
Torque |
Speed (60° rotation) |
|
6.0V |
22.2 kg-cm (308.4 oz-in) |
0.12 sec |
|
7.4V |
26.7 kg-cm (370.9 oz-in) |
0.10 sec |
|
8.4V |
30.5 kg-cm (423.6 oz-in) |
0.08 sec |
Power Requirements
Voltage range: 4.5V–8.5V (supports 4–6 cell NiMH, 2S LiPo, or 2S LiFe batteries).
Control Features
Digital control with 12-bit (4096-step) resolution
Deadband: 0.001 ms (default 1 µs)
Build Quality
Dual ball bearings
Tough steel alloy gears
High-end coreless motor
25T spline (F-type compatible) for horns/gears
Dimensions & Weight
Size: 40.6 × 20.6 × 39.7 mm (1.6 × 0.81 × 1.56 in)
Weight: 71 g (±1 g / 2.50 oz)
