Blue Bird BMS-373 – Compact Micro Analog Servo

Servo Type

Micro, Analog control (BMS-373 platform)

Torque @ 4.8V

22.0 oz-in / 1.6 kg-cm (approx.)

Speed @ 4.8V

0.12 sec / 60°

Speed @ 6.0V

0.08–0.10 sec / 60° (typical for platform variants)

Shaft Power

≈0.34 W

Weight

≈9.6 g / 0.34 oz (BB variant); base BMS-373 ≈9 g class

Dimensions

≈24.5 x 11.5 x 23 mm / 0.97 x 0.45 x 0.91 in

Gear Material

Nylon/plastic (standard); metal-gear MG variant available

Gear Spline

25 Teeth

Rotation Support

Bushing (standard); ball-bearing (BB variant)

Motor

3-pole brushed motor

Connector

Universal (JR/Futaba/Hitec compatible)

Certification

CE certified, low RF-noise motor design
